Caractéristiques techniques:
Cadre:
- Cadre:
Sprint carbon monocoque, mechanical/electronic, BB-PressFit 86,5x41, head tube 1.4"-1.5", integrated seat clamp, full carbon dropout, Disc brake flat mount, thru axle 12 x 142 sizes 47-50-53-55-57-59-61cm
- Fourche:
Full Carbon Aero Road 1.4">1.5" integrated head , Disc brake flat mount, thru axle 12x100 Transmission:
- Pédalier:
Shimano 105 12v / manivelles:
170mm-47/53cm, 172.5mm-55/59cm, 175mm-61cm
- Cassette:
Shimano 11-32
- Chaine:
Shimano 12v
- Poignées:
Shimano 105 freins à disques hydrauliques
- Dérailleur avant:
Shimano 105 12v, 50-54T
- Dérailleur arrière:
Shimano 105 12v, max 36T Freinage:
- Freins:
Shimano, Hydraulic disc brake, included in the shifter
- Disques:
Shimano rotor for disc brake center lock, SM-RT70, 160mm Composants:
- Cintre:
Velomann Compact, alloy 6061, diam . 31,8mm, reach 80mm, drop 130mm Size: 400mm-44/53cm,420mm-55/59cm,440mm-61cm
- Potence:
Velomann, Alloy 6061, raise
- 7° Ext: 80mm-44cm, 90mm-47/50cm, 100mm-53cm, 110mm-55/57cm, 120mm-59/61cm
- Selle:
Velomann Seta
- Tige de selle:
Velomann alloy 6061, 15mm offset, 27,2mm; Length: 300mm-44cm ; 350mm-47/61cm Roues:
- Roues:
Velomann VR 30 Alu
- Pneus:
Vittoria Rubino IV G2.0 graphene, 700x25, 60TPI Informations générales:
- Coloris:
SZ Light Grey Graphite Race Glossy
- Tailles:
47, 50, 53, 55, 57, 59
- Poids:
8,85 kg Géométrie:
(mm) 47 50 53 55 57 59 61 A 497 505 529 545 561 580 599 B 377 383 384 388 393 396 397 C 105 110 125 140 155 175 195 D 420 450 480 500 520 540 560 E 515 525 535 550 560 575 585
